A motor bridge funnel is the ship's exhaust funnel positioned to safely release engine gases away from the navigation bridge while maintaining visibility and operational safety.

Function and Placement

A funnel on a ship acts as a chimney for the engine exhaust gases, directing them safely into the atmosphere and away from the ship's deck and navigation bridge . Its cross-section and inclination are designed to ensure that exhaust gases do not obstruct the bridge or crew visibility. Typically, the funnel is angled aft to assist the flow of flue gases away from the bridge, preventing interference with navigation and reducing the risk of soot or sparks affecting the deck .

Relation to the Navigation Bridge

The navigation bridge is the control center of the ship, often located above the accommodation block. The funnel's placement is critical to ensure clear visibility from the bridge, especially during maneuvers or stern-first operations . On some ships, bridge wings and funnel orientation are adjusted to maximize visibility while maintaining safe exhaust discharge.

Operational Considerations

• Soot and Spark Management: Sparks from the funnel can occur due to unburnt soot in the exhaust system, improper cylinder lubrication, or delayed maintenance of the exhaust gas boiler. Regular soot blowing, water washing, and inspection of funnel wire mesh are essential to prevent fires .
• Safety Measures: Combustible materials should be cleared from the vicinity of the funnel, and fire watches should be maintained during operations that may produce sparks .
• Environmental Compliance: Modern funnels often include emission control systems to limit pollutants, with collected residues managed according to port regulations .

Summary

The motor bridge funnel is a critical component that integrates engine exhaust management with bridge safety and visibility. Proper design, maintenance, and operational procedures ensure that exhaust gases are safely discharged without compromising navigation or crew safety, while also meeting environmental standards .
