Secondary Distribution Boxes (SDBs) come in standardized dimensions based on application, load, and installation type, with typical sizes ranging from compact wall-mounted units to larger underground enclosures.

Overview of Secondary Distribution Boxes

A Secondary Distribution Box (SDB) receives power from the main distribution board and distributes it to branch circuits or floor modules. SDBs can be fitted with terminal blocks for custom wiring and are often finished in powder-coated black for durability and corrosion resistance (GlobalIFS) . They are used in residential, commercial, and light industrial settings, and can be wall-mounted or installed underground.

Standard Dimensions

Wall-Mounted SDBs

• Width: Typically 200–600 mm
• Height: 300–800 mm
• Depth: 100–300 mm
• These dimensions allow for sufficient space for terminal blocks, wiring, and heat dissipation (Carsai) .
• Slot or way counts vary from 1-way to 36-ways depending on the number of circuits (Slideshare) .

Underground Enclosures

• Non-concrete enclosures: Designed for incidental loading, often polymer concrete covers with slip-resistant surfaces.
• Concrete enclosures: Required for vehicular traffic areas, compliant with ASTM C-857.
• Typical dimensions: Length 600–1200 mm, Width 400–800 mm, Height 300–600 mm, depending on manufacturer and load requirements (PG&E) .
• Covers must include manufacturer labeling, PG&E identification, and high-friction surfaces for safety.

Depth and Volume Considerations

• Depth is critical for accommodating conductors, devices, and heat dissipation.
• Deeper boxes are used for higher amperage or multiple circuits.
• Volume is calculated as internal cubic space and should allow for future expansion or additional wiring (Carsai) .

Material and Compliance

• Materials: Powder-coated steel, polymer concrete, or precast concrete.
• IP Ratings: For outdoor or industrial applications, IP44 to IP67 is common to ensure water and dust resistance (Accio) .
• Standards: Must comply with local electrical codes (NEC, IEC) and manufacturer specifications for safety, load, and installation.

Selection Tips

1. Determine load requirements: Match amperage and number of circuits to box size.
2. Consider installation type: Wall-mounted vs. underground affects dimensions and material.
3. Plan for expansion: Choose a box with extra volume for future circuits or EV charger integration.
4. Check compliance: Ensure IP rating, fire rating, and code compliance for your region.
5. Ease of installation: Pre-wired or modular SDBs can reduce installation time and improve safety. By understanding these dimensions and specifications, you can select the appropriate secondary distribution box for your electrical system, ensuring safety, compliance, and future-proofing.
